MEA-065A24C DELTA

Fiche technique

Output Current

2.71A

Output Voltage

24V

Output Power

65W

Line Regulation

± 0.5%

Load Regulation

± 4.5%

Hold-up Time

10ms typ. @ 115Vac

Dynamic Response (Overshoot and Undershoot O/P Voltage)

± 10% @ 0-50% & 50-100% load; Slew rate 0.25A/µs (@ 100Hz, 50% Duty Cycle)

Nominal Input Voltage

100-240Vac

Input Voltage Range

90-264Vac

Nominal Input Frequency

50-60Hz

Input Frequency Range

47-63Hz

Input Current

1.5A @ 115Vac, 0.75A @ 230Vac

Case Chassis / Cover

PC

Operating Temperature

-10°C to +60°C

Storage Temperature

-40°C to +85°C

Operating Humidity

10-95% RH (Non-Condensing)

Shock Test (Non-Operating)

50G, 11ms, 3 shocks for each direction

Vibration (Non-Operating)

5-500Hz, 2.09Grms, 20 minute for each three axis

Operating Altitude

Up to 5,000 meters (up to 16,400 feet or 106-54kPa)

Overvoltage

150% max, Latch Mode

Over Temperature

Latch Mode

Short Circuit

Hiccup Mode, (Non-Latching, Auto-Recovery)

Degree of Protection

IP22

Protection Against Shock

Class I

MTBF

1 million Hours based on Telecordia SR-332 (at 115Vac, Max. load and 25°C Ambient)

CE

In conformance with EMC Directive 2014/30/EU and Low Voltage Directive 2014/35/EU EN 60601-1: 2006 + A11: 2011 + A1: 2013 + A12: 2014 & EN 60601-1-2: 2015

UKCA

In conformance with Electrical Equipment (Safety) Regulations 2016 and Electromagnetic Compatibility Regulations 2016, Medical Devices Regulations 2002(UK MDR 2002)

Emission

EN/BS EN 55011 Class B Compliance to EN/BS EN 55032, FCC Title 47: Class B

Harmonic Current Emissions

IEC61000-3-2

PARD

1%

Leakage Current

0.2mA @ 264Vac NC2), 0.5mA @ 264Vac SFC3)

Voltage Fluctuation and Flicker

IEC61000-3-3

Inrush Current

50A @ 115Vac and 100A @ 230Vac

Indicator

Green LED
