D2T-0423-E-B4 HIWIN FD00AMD21031 EF0171A2

Servo Drive of the 17-bit D2T series, with excellent performances: High response speed greater than 1200Hz thanks to high-end semiconductors; High-speed response by using advanced controller design tools and space vector control technology achieving a high level of servo performance. The speed of the servomotor can change from -3000 to +3000rpm in just 0.006 seconds; Built-in function of precision improvement, optimizing system behavior by including tables up to 5000 points; Function of vibration suppression during movement caused by the system structure improving machine production; Electronic transmission ratio and encoder emulator, adjusting the resolution of impulses for the PLC and working with a different position encoder. Power voltage 200-240Vac; Supports ±10V voltage or digital commands for speed or strength / torque modes; Supports STP / DIR, CW / CCW, A/B pulse formats (high/low speed channels); Easy-to-operate intuitive software by sorting parameters by features and not using confusing lists;
