DRN-24V7AAEN DELTA

Ficha técnica

Output Current

40A

Output Voltage

24V

Case Chassis / Cover

Metal

Cooling System

Convection

Storage Temperature

-15°C to +40°C

Operating Humidity

5 to 95% RH (Non-Condensing)

Vibration (Non-Operating)

IEC 60068-2-6, 10 Hz to 500 Hz @ 30 m/s² (3 G peak); 60 min per axis for all X, Y, Z direction

Degree of Protection

IP00

CE

In conformance with EMC Directive 2014/30/EU and Low Voltage Directive 2014/35/EU

UKCA

In conformance with Electromagnetic Compatibility Regulations 2016 and Electrical Equipment (Safety) Regulations 2016

Shock Test (Non-Operating)

IEC 60068-2-27, 30 G (300 m/s²) for a duration of 18 ms, 1 time per direction, 2 times in total

Protection Against Shock

Class III

Wire

Battery: AWG 10-6 (Load: 0-20 A), AWG 8-6 (Load: 20-40 A)

Operating Altitude

0 to 6000 m

Pollution Degree

2

Internal Fuse

30 A
